0507269 PANDUIT IT9115-CUV8 Brida Gris Cable Tie 15.3P
0507269 PANDUIT IT9115-CUV8 Brida Gris Cable Tie 15.3P
  • Control Edificios
  • VDI
  • VDI ELEMENTOS PASIVOS
Cod. 0507269   EAN 0074983504046

PANDUIT

PANDUIT IT9115-CUV8 Brida Gris Cable Tie 15.3P

Entrega a consultar

  (Ver +)

Múltiplo venta: 100,00 uds.

767,77€/M



Impuestos no incluidos.

Si estás buscando algún producto con urgencia y no lo encuentras, ponte en contacto con nosotros y trataremos de conseguírtelo rápidamente.

Puedes escribirnos un email o llamarnos por teléfono:

Buscar Punto de Venta

PANDUIT IT9115-CUV8 Brida Gris Cable Tie 15.3P

Cable Tie, In-Line, 15.3 Inches (389 mm) Length, Light-Heavy, Weather Resistant Nylon 6.6, Gray color to match the foam. Lasts 2-3 times longer than normal pigmented colors. No protruding head to cause injury since head is inverted. No protruding tie tip to cause injury since the tip is trapped between the tie and the foam. Tie will not slip on the foam since the head will indent the foam to remain captive. Wide tie body 0.35 inch (8.9 mm) for improved aesthetics. Cannot over-tension tie causing bulges in the foam. Install by hand or use Panduit GTH-E installation tool. Flexible and easy to handle and install. No need to heat weld the ends closed. No cut-off scrap pieces to handle or pick up. Strong 124 pound (552 Newton) minimum loop tensile strength. Locking wedge is protected from unlocking and from ultraviolet light exposure. Ties are installed with the teeth on the inside against the foam.

Características detalladas

Fluorescente No
Área de impresión Ninguno
Estable a los rayos UV según ASTM D6779 Sí
Longitud de la banda 389 mm
Cierre desmontable No
Transparente No
Cierre de cinta Borde/abrazadera de plástico
Tratamiento de superficie Sin tratamiento
Espesor de la cinta 1.7 mm
Aprobación de VG No
Libre de halógenos Sí
Clase de inflamabilidad de material aislante V2
Temperatura de operatividad -60 ~85 °C
Calidad del material Poliamida (PA)
Mínima resistencia a la tracción 552 N
Homologación MIL No
Tipo de fijación Ninguno
Material Plástico
Color Gris
Modelo Dentado externo
Aprobación UL No
Diámetro máximo del paquete 115
Temperatura de instalación -20 ~85 °C
Ancho de la banda 8.9 mm

Embalaje 1

  • Cantidad mínima embalaje: 1000
  • Cantidad máxima embalaje: 1000
  • Medidas: 0,45 x 0,21 x 0,07 (m)
  • Volumen: 0,00 m3
  • Peso: 0,73 kg
